Digital Signage: Ensuring outdoor readability

A1

Photos courtesy Nanov Display

By Myung Kune Moon
Outdoor digital signage deployments face many challenges from the elements, particularly in Canadian climates. Screens must be kept watertight to prevent damage by rain and snow. Systems need to be able to operate continuously at extreme temperatures, from cold winters to hot summers. They need to be protected against dirt, brake dust, fumes and other airborne particles. Depending on their location, they must be engineered to sustain local wind loads, including hurricane levels in coastal regions. And they must address the threat of vandalism.

One particular ongoing challenge, however, is ensuring outdoor digital signs can be easily read by passersby. Among the elements, the main threat to readability is direct sunshine. There are several ways to make sure liquid crystal displays (LCDs) remain readable under sunny conditions, including: increasing brightness with light-emitting diode (LED) backlighting units (BLUs); optical bonding of the panel to glass; and placing a transflective film behind the panel.

Transmissive, reflective and transflective
The most common indoor digital signs are transmissive LCDs, which are installed with BLUs as their light source and do not use any reflective film behind their panels. So long as ambient light sources are not as strong as the BLUs, these screens can be seen well. This means they are readable in areas with little light or in complete darkness. Outdoors, however, daylight is stronger than the BLUs, so it is no longer possible to clearly see this type of screen’s content.

There are also reflective LCDs, where a reflective film is placed behind the screen, with no BLUs. These screens are only visible with the help of ambient light, whether from the sun or from other lamps. And in darkness, they are not readable at all.

To gain the benefits and to avoid the drawbacks of both transmissive and reflective LCDs, another option is to place a transflective film behind the screen, which cannot be permeated by light from the front, but allows light from the back to enter cleanly. In this way, a digital sign can be seen clearly under bright outdoor conditions, but will also reproduce its content’s colours naturally and remain highly bright at night or other under dark conditions (e.g. cloud cover).

You May Also Like   Digital Signage: Outdoor options for scalability and connectivity

Transflective films have been shown to optically increase screen brightness by 30 per cent. An anti-reflection coating reduces glare on the surface. And perhaps most effectively of all, transflective film actually ‘recycles’ sunlight, by reflecting it from inside the panel so as to reuse it as a backlighting source. Thus, when sunlight becomes stronger, the panel actually becomes brighter.

Standard-vs-transflective_Sunlight-Readable

Recent research and development (R&D) of transflective films have yielded more easily legible displays.

Pros and cons
There are advantages and disadvantages to the different measures that can be taken to make LCDs more clearly readable outdoors.

Increasing the brightness of an LCD’s BLUs and adding a transflective film during the manufacturing process will both mean increases in costs. Moreover, transflective films can be difficult (a) to source and (b) to place behind the LCD panel. A class 100 clean room is recommended for this process.

That said, numerous sunlight readability tests with various films, panel sizes and installation positions have helped technicians achieve optimum visibility for mass-produced large-format LCDs, including units that have already performed well in Canadian weather conditions.

One advantage of creating a transflective LCD over adding moer LED BLUs is energy efficiency. For heat management purposes, LEDs need to be kept cool through the use of fans, which consume electricity. A transflective film means less cooling is needed and, thus, less energy is consumed.

There are also savings in weight. A transflective LCD is lighter than comparable outdoor screens and therefore more easily portable.
